Low Noise Nema 23 Stepping Motor Phase 3 1.2 Degree 4.6 V 5.2 A
| Place of Origin | China |
|---|---|
| Brand Name | TB-Motor |
| Certification | CE ROHS ISO |
| Model Number | 57BYGH350C-001-14 |
| Minimum Order Quantity | 50 |
| Price | USD |
| Packaging Details | Carton with Inner Foam Box, Pallet |
| Delivery Time | 25 DAYS |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 PCS/MONTH |
Leave a Message
Product Details
| Product Name | Hybrid Stepping Motor | Step Accuracy | ± 5% |
|---|---|---|---|
| Current | 5.2 A | Step Angle | 1.8 Degree |
| Insulation Resistance | 100MΩ Min.500VC DC | Rated Voltage | 4.6 V |
| Number Of Phase | 3 | Ambient Temperature | -20℃~+50℃ |
| Holding Torque | 12 Kg.cm | Certification | CE ROHS ISO |
| Resistance | 0.8 Ohms/Phase | Inductance | 1.4 MH/Phase |
| High Light | Low Noise Nema 23 Stepping Motor,1.2 Degree Nema 23 Stepping Motor,Phase 3 Hybrid Stepper Motor 4.6V | ||
Product Description
Stepping Motor Phase 3 Nema 23 1.2 Degree 4.6 V Low Noise Wholesale 5.2 A
Nema23 3 Phase Stepper Motors. High torque, Low noise, Step Angle 1.2 Degree.
The stepper motor is a digital input-output device. It is particularly well suited to the type of application where control signals appear as digital pulses rather than analog voltages. One digital pulse to a stepper motor drive or translator causes the motor to increment one precise angle of motion. As the digital pulses increase in frequency, the step movement changes into continuous rotation.
Some industrial and scientific applications of stepper motors include robotics, machine tools, pick and place machines, automated wire cutting and wire bonding machines, and even precise fluid control devices.
| Number Of Phase | 3 | Comment |
| Step Angle | 1.2°/Step |  |
| Rated Voltage | 4.6 V | |
| Current | 5.2 A/Phase | |
| Resistance | 0.8 Ohms/Phase | |
| Inductance | 1.4 MH/Phase | |
| Holding Torque | 12 Kg.cm | |
| Insulation Class | B |
