3.8 Kg Cm Nema 23 High Torque Hybrid Stepper Motor 6 Wire 11.2V 0.4A 57mm

Place of OriginChina
Brand NameTB-Motor
CertificationCE ROHS ISO
Model Number57BYGN204
Minimum Order Quantity50
PriceUSD
Packaging DetailsCarton with Inner Foam Box, Pallet
Delivery Time25 DAYS
Payment TermsL/C, D/P, T/T, Western Union, MoneyGram
Supply Ability10000 PCS/MONTH
GET AN ESTIMATE NOW

Leave a Message

Product Details



Product NameHybrid Stepping MotorStep Accuracy± 5%
Insulation Resistance100MΩ Min.500VC DCHolding Torque0.38Nm
Ambient Temperature-20℃~+50℃Dielectric Strength500VAC 1 Minute
Max Radial Force75N (20mm From Front Flange)Max Axial Force15N
Voltage11.2VTemperature Rise80 ℃ Max
High Light
nema 23 3.8 kg cm hybrid stepper motor,nema 23 57mm Stepper Motor,1.8 stepper motor nema 23



Product Description



57BYGN204 low noise NEMA 23 hybrid stepper motor 11.2V 0.4A can be customized

57BYGN204, Voltage 11.2V, Current 0.4A, Holding torque 3.8 Kg.cm, Resistance 28 Ω/phase

57BYGN001, Voltage 12V, Current 0.38A, Holding torque 3.0 Kg.cm, Resistance 32 Ω/phase

57BYGN027, Voltage 2.8V, Current 1.4A, Holding torque 3.9 Kg.cm, Resistance 2.1 Ω/phase

Electrical Specification

Model Number
  57BYGN204
Step Accuracy
± 5%
Step Angle
1.8°
Lead Wire
6
Voltage (V)
11.2
Current (A/Phase)
0.4
Holding Torque (Kg.cm)
3.8
Resistance (Ω/phase)28
Inductance (mH/phase)30
Motor length (MM)51
Motor Weight(Kg)0.6
Insulation ClassB

*Products can be customized by special request.



Wiring Diagram

3.8 Kg Cm Nema 23 High Torque Hybrid Stepper Motor 6 Wire 11.2V 0.4A 57mm 0
 Mechanical Dimension
3.8 Kg Cm Nema 23 High Torque Hybrid Stepper Motor 6 Wire 11.2V 0.4A 57mm 1
Specification of Other Models:
MODELSTEP ANGLE
(°/STEP)
LEAD WIRE
(NO.)
VOLTAGE
(V)
CURRENT
(A/PHASE)
RESISTANCE
(Ω/PHASE)
INDUCTANCE
(MH/PHASE)
HOLDING TORQUE
(KG.CM)
MOTOR HEIGHT
L(MM)
MOTOR WEIGHT
(KG)
57BYGN0011.86120.3832253.0410.45
57BYGN0271.842.81.42.13.53.9410.45
57BYGN200-19A1.8651.05.011.55.8510.65
57BYGN2041.8611.20.428303.8510.65
57BYGN400-11A1.845.51.15.0127.8560.70
57BYGN4121.844.42.02.26.39.0560.70



*Products can be customized by special request.

*Can match with gearbox 42, 52, 56



Product Range Of TB-Motor
pl105459856 remark

Based on all this advantages, our company specializes in producing hybrid stepping motors, DC brushless motors, servo motors, gearbox motors and so on. The products are applied in robots, packing machinery, textile machinery, medical instruments, printing machinery, intelligent logistics equipment… TB-Motor also sends its products to USA, Europe, Southeast Asia and all-around China.

3.8 Kg Cm Nema 23 High Torque Hybrid Stepper Motor 6 Wire 11.2V 0.4A 57mm 3

Advantages:

1. The rotation angle of the motor is proportional to the input pulse.

2. The motor has full torque at standstill(if the windings are energized)

3. Precise positioning and repeatability of movement since good stepper motors have an accuracy of 3 – 5% of a step and this error is noncumulative from one step to the next.

4. Excellent response to starting/stopping/reversing.

5. Very reliable since there are no contact brushes in the motor. Therefore the life of the motor is simply dependant on the life of the bearing.

6. The motors response to digital input pulses provides open-loop control, making the motor simpler and less

costly to control.

7. It is possible to achieve very low-speed synchronous rotation with a load that is directly coupled to the shaft.

8. A wide range of rotational speeds can be realized as the speed is proportional to the frequency of the input

pulses.
