42mm 68 Oz-In 6.56v 2 Phase Stepper Motor Gear Box Planetary Gearbox 42BYGH868-14AG5
| Place of Origin | China |
|---|---|
| Brand Name | TB-Motor |
| Certification | CE ROHS ISO |
| Model Number | 42BYGH868-14AG5 |
| Minimum Order Quantity | 50 |
| Price | USD |
| Packaging Details | Carton with Inner Foam Box, Pallet |
| Delivery Time | 25 DAYS |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 PCS/MONTH |
Leave a Message
Product Details
| Product Name | Stepping Gearbox Motor | Step Angle | 1.8° |
|---|---|---|---|
| Step Accuracy | ± 5% | HOLDING TORQUE | 4.9 Kg.cm |
| Temperature Rise | 80 ℃ Max | Insulation Resistance | 100MΩ Min.500VC DC |
| Ambient Temperature | -20℃~+50℃ | Housing Material | Powder Metallurgy |
| Bearing At Output | Sleeve Bearing | IP Level | IP40 |
| High Light | 2 Phase Stepper Motor Gear Box,2 Phase Stepper Motor Planetary Gearbox,42mm Gearbox Stepper Motor | ||
Product Description
42mm 68 Oz-In 6.56v 2 Phase Stepper Motor Gear Box Planetary Gearbox 42BYGH868-14AG5
The stepper gearbox is 1.8° step angle and the insulation class is B. The advantage of the motor is low speed and stability.
With 36mm Powder metallurgy, the motor has longer service life and quality performance.
Electrical Specification
| 42BYGH868-14AG5 | ||
| STEP ANGLE | °/STEP | 1.8 |
| RATED VOLTAGE | V | 6.56 |
| CURRENT | A/PHASE | 0.8 |
| RESISTANCE | Ω/PHASE | 8.2 |
| INDUCTANCE | mH/PHASE | 13.8 |
| HOLDING TORQUE | kg.cm | 4.9 |
| INSULATION CLASS | B | |
*Products can be customized by special request.
Wiring Diagram
Mechanical Dimension
Product Application
Smart guide robot motor
GEARBOX Electrical Specification
Out diameter 36mm Powder metallurgy
| Housing material | Bearing at output | Radial load(10mm from flange)N | Shaft axial load(N) | Shaft press-fit force max(N) | Radial play of shaft(mm) | Thrust play of shaft(mm) | Backlash at no-load (°) |
| Powder metallurgy | sleeve bearing | ≤120 | ≤80 | ≤500 | ≤0.03 | ≤0.1 | ≤1.5 |
| Reduction ratio | Rated tolerance torque (Nm) | Max momentary tolerance torque (Nm) | Efficiency% | Length (mm) | Weight(g) | Number of gear trains |
| 1/4 | 0.3 | 1.0 | 81% | 24.8 | 145 | 1 |
| 1/5 | ||||||
| 1/16 | 1.2 | 3.5 | 72% | 32.4 | 173 | 2 |
| 1/20 | ||||||
| 1/25 | ||||||
| 1/53 | 2.5 | 7.5 | 65% | 41.9 | 213 | 3 |
| 1/62 | ||||||
| 1/76 | ||||||
| 1/94 | ||||||
| 1/117 |
Mechanical Dimension
