High Torque Hybrid Stepper Motor 110 mm 1.2 degree 4 Wire 110BYGH99 001 4.95 Voltage
| Place of Origin | China |
|---|---|
| Brand Name | TB-Motor |
| Certification | CE ROHS ISO |
| Model Number | 110BYGH99-001 |
| Minimum Order Quantity | 50 |
| Price | USD |
| Packaging Details | Carton with Inner Foam Box, Pallet |
| Delivery Time | 25 DAYS |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 PCS/MONTH |
Leave a Message
Product Details
| Product Name | Hybrid Stepping Motor | Step Accuracy | ± 5% |
|---|---|---|---|
| Temperature Rise | 80 ℃ Max | Inductance | 14.0 MH |
| Ambient Temperature | -20℃~+50℃ | Weight | 5kg |
| Dielectric Strength | 500VAC 1 Minute | Insulation Resistance | 100MΩ Min.500VC DC |
| Max Radial Force | 330N (20mm From Front Flange) | Max Axial Force | 100N |
| High Light | High Torque Hybrid Stepper Motor 1.2 Degree,Hybrid Stepper Motor 1.2 Degree 4 Wire,stepper motor 110mm 110BYGH99 | ||
Product Description
110BYGH99-001 High Torque Output 4.95 Voltage Customizable Hybrid Stepping Motor
The stepper motor working principle is Electro-Magnetism. It includes a rotor which is made with a permanent magnet whereas a stator is with electromagnets. Once the supply is provided to the winding of the stator then the magnetic field will be developed within the stator. Now rotor in the motor will start to move with the rotating magnetic field of the stator. So this is the fundamental working principle of this motor
| Model Number | 110BYGH99-001 |
| Step Accuracy | ± 5% |
| Step Angle | 1.2° |
| Lead Wire | 4 |
| Voltage (V) | 4.95 |
| Current (A/Phase) | 11.2 |
| Resistance (Ω/phase) | 0.9 |
| Inductance (mH/phase) | 14.0 |
| Motor length (MM) | 99 |
| Motr Weight(K/g) | 5 |
| Insulation Class | B |
*Products can be customized by special request.
Wiring Diagram
Mechanical Dimension
| MODEL | STEP ANGLE (°/STEP) | LEAD WIRE (NO.) | VOLTAGE (V) | CURRENT (A/PHASE) | RESISTANCE (Ω/PHASE) | INDUCTANCE (MH/PHASE) | HOLDING TORQUE (N.M) | MOTOR HEIGHT L(MM) | MOTOR WEIGHT (KG) |
|---|---|---|---|---|---|---|---|---|---|
| 110BYGH80-001AG | 1.8 | 4 | 9.0 | 6.0 | 1.5 | 14.0 | 8.5 | 80 | 5.0 |
| 110BYGH99-001-10 | 1.8 | 4 | 4.95 | 5.5 | 0.9 | 12.0 | 11.2 | 99 | 5.0 |
| 110BYGH150-001 | 1.8 | 4 | 5.44 | 6.8 | 0.8 | 12.0 | 21 | 150 | 8.4 |
| 110BYGH165-001-03 | 1.8 | 4 | 4.80 | 6.0 | 0.8 | 14.0 | 24 | 165 | 9.5 |
| 110BYGH201-001 | 1.8 | 4 | 5.36 | 8.0 | 0.76 | 16.0 | 30 | 201 | 12.0 |
