Hybrid Type Stepper Motor Nema 16 39mm 0.3a 0.08 Nm 78 oz in High Speed
| Place of Origin | China |
|---|---|
| Brand Name | TB-Motor |
| Certification | CE ROHS ISO |
| Model Number | 39BYG019-01A |
| Minimum Order Quantity | 50 |
| Price | USD |
| Packaging Details | Carton with Inner Foam Box, Pallet |
| Delivery Time | 25 DAYS |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 PCS/MONTH |
Leave a Message
Product Details
| Product Name | Hybrid Stepping Motor | Step Accuracy | ± 5% |
|---|---|---|---|
| Temperature Rise | 80 ℃ Max | Insulation Resistance | 100MΩ Min.500VC DC |
| Dielectric Strength | 500VAC 1 Minute | Ambient Temperature | -20℃~+50℃ |
| Max Radial Force | 28N (20mm From Front Flange) | Max Axial Force | 10N |
| IP Level | IP40 | Voltage | 12.9V |
| High Light | Hybrid Type Stepper Motor 39mm,nema 16 high torque stepper motor 78 oz in,stepper motor nema 16 | ||
Product Description
39BYG019-01A Customizable 48V Nema16 High Quality Stepper Motor High Speed Dc Stepper Motor
Stepper motors are DC motors that move in discrete steps. They have multiple coils that are organized in groups called “phases”. By energizing each phase in sequence, the motor will rotate, one step at a time.
Electrical Specification:
Model Number | 39BYG019-01A |
Step Accuracy | ± 5% |
Step Angle | 1.8° |
Lead Wire | 4 |
Voltage (V) | 12.9 |
Current (A/Phase) | 0.3 |
Holding Torque (N.m) | 0.08 |
| Resistance (Ω/phase) | 28 |
| Inductance (mH/phase) | 21 |
| Motor length (MM) | 20 |
| Motr Weight(K/g) | 0.12 |
| Insulation Class | B |
*Products can be customized by special request.
Wiring Diagram
Mechanical Dimension
Specification of Other Models:
| MODEL | Step Angle (°/Step) | Lead Wire (NO.) | Voltage (V) | Current (A/Phase) | Resistance (Ω/Phase) | Inductance (MH/Phase) | Holding Torque (G.CM) | Motor Height L(MM) | Motor Weight (KG) |
|---|---|---|---|---|---|---|---|---|---|
| 39BYGX001A | 1.8 | 4 | 13.44 | 0.48 | 28 | 21 | 1000 | 20 | 0.10 |
| 39BYGX002A | 1.8 | 4 | 8.4 | 0.7 | 12 | 11 | 1200 | 20 | 0.10 |
| 39BYGX100A | 1.8 | 4 | 12 | 0.4 | 30 | 20 | 1300 | 22 | 0.12 |
| 39BYGX200A | 1.8 | 4 | 14.4 | 0.4 | 36 | 33 | 1700 | 25 | 0.14 |
*Products can be customized by special request.
*Produdts can match gearbox 36
