Low Noise Customizable Dc Brushless Motor 86BLF06C 48v Nema 34 2 A 0.1 OHMS

Place of Origin	China
Brand Name	TB-Motor
Certification	CE ROHS ISO
Model Number	86BLF06C
Minimum Order Quantity	50
Price	USD
Packaging Details	Carton with Inner Foam Box, Pallet
Delivery Time	25 DAYS
Payment Terms	L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability	10000 PCS/MONTH

GET AN ESTIMATE NOW

Product Details

Product Name	Brushless DC Motor	Nominal Voltage	48V
Hall Effect Angle	120° Electrical Anglel	Winding Type	Star
No-load Speed	4000 Rpm	No-load Current	18 Apms
Rated Speed	3000± 300 Rpm	Back Emf Constant	12 V/kRPM
Rated Torque	1.8 N.m	Torque Constant	0.11 N.m/A
Cetification	CE ROHS ISO	Max Radial Force	22 0N (10mm From Front Flange)
Max Axial Force	60 N	Insulation Class	B
High Light	48v Dc Brushless Motor,Nema 34 Dc Brushless Motor,0.1 OHMS Brushless DC Motor

Product Description

Low Noise Customizable Dc Brushless Motor 86BLF06C 48v Nema 34 2 A 0.1 OHMS

Are you looking for a high-reliability, high-efficiency and high power-to-size ratio motor? The obvious solution is a Brushless DC (BLDC) motor. It shares many of the same torque and speed characteristics with the Brushed DC (BDC) motor but does not include the brushes. Technically, it is a Permanent Magnet Synchronous Motor (PMSM), but it’s named Brushless DC as it operates from a DC power supply using an inverter with a simple commutation method and that there are no brushes involved. In some cases, the stator windings are constructed to match the non-sinusoidal commutation.

Brushless DC motor (BLDC motors) also known as electronically commutated motors are synchronous motors powered by DC electricity via an inverter or switching power supply which produces an AC electric current to drive each phase of the motor via a closed loop controller.

Electrical Specification

ROTATION: CW SEE FROM LWAD END

Manufacture Model		86BLF06C
Resistance	OHMS	0.1
Nominal Voltage	VDC	48
Rated Speed	Rpm	3000± 300
Rated Current	A	2
Rated Torque	N.m	1.8
No-load Speed	Rpm	4000
No-load Current	Amps	2
Torque Constant	N.m/A	0.11
Back EMF constant	V/kRPM	12
Insulation Class		B
