Miniature Brushless Dc Motor 42mm 24v Dc 4000 Rpm 3 Phase 78W 0.063nm 42BLF03
| Place of Origin | China |
|---|---|
| Brand Name | TB-Motor |
| Certification | CE ROHS ISO |
| Model Number | 42BLF03 |
| Minimum Order Quantity | 50 |
| Price | USD |
| Packaging Details | Carton with Inner Foam Box, Pallet |
| Delivery Time | 28-31 |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 5000pcs/month |
Leave a Message
Product Details
| Product Name | Brushless DC Motors | Rated Voltage | 24V |
|---|---|---|---|
| Power | 78W | Rated Torque | 0.188 N.m |
| Motor Length | 79mm | Winding Type | Star |
| Hall Effect Angle | 120° Electrical Angle | Insulation Resistance | 100MΩ Min.500VC DC |
| MAX Radial Force | 15N (10mm From Front Flange) | MAX Axial Force | 10N |
| Insulation Class | B | IP Level | IP40 |
| High Light | Brushless Dc Motor 24vdc 4000rpm 0.063nm,Pm Brushless Dc Motor 0.063nm,42mm brushless dc motor 0.063nm | ||
Product Description
42BLF03 42mm*42mm*79mm 24V 4000RPM 3 phase 78W micro brushless dc motor
Part number: 42BLF03
Resistance: 0.57±10% OHMS
No-load speed: 5000±10%
No-load current: 0.8 A
Winding Type: Star
Insulation Resistance: 100MΩ Min.500VC DC
The 42BLF series is one of the most regular brushless motors applied in the automation industry.
Electrical Specification:
| Model | ||||
| Specification | Unit | 42BLF01 | 42BLF02 | 42BLF03 |
| Number Of Phases | Phase | 3 | ||
| Number Of Poles | Poles | 8 | ||
| Rated Voltage | VDC | 24 | ||
| Rated Speed | Rpm | 4000 | ||
| Rated Current | A | 1.5 | 3.1 | 4.17 |
| Rated Torque | N.m | 0.063 | 0.130 | 0.188 |
| Rated Power | W | 26 | 54 | 78 |
| Peak Torque | mN.m | 0.189 | 0.390 | 0.560 |
| Peak Current | Amps | 4.5 | 9.3 | 12.5 |
| Torque Constant | N.m/A | 0.042 | 0.042 | 0.045 |
| Body Length | mm | 47 | 63 | 79 |
| Weight | Kg | 0.30 | 0.45 | 0.60 |
***Note: The products can be customized by your request. Please contact us for more details.
*Products can match gearbox 36,42mm
| ELECTRICAL CONNECTION TABLE | ||
| FUNCTION | COLOR | |
| +5V | RED | UL1007 26AWG |
| HALL A | YELLOW | |
| HALL B | GREEN | |
| HALL C | BLUE | |
| GND | BLACK | |
| PHASE A | YELLOW | UL3265 22AWG |
| PHASE B | GREEN | |
| PHASE C | BLUE | |
Brushless motors have significantly higher efficiency and performance, and a lower susceptibility to mechanical wear than their brushed counterparts.
Brushless Motor Application
Transport
Medical Instruments
Heating and ventilation
Textile Machinery
Motion control systems
Positioning and actuation systems
etc
