Miniature Linear Stepper Motor Nema 17 42bygh

Place of OriginChina
Brand Name TB-Motor
CertificationCE ROHS ISO
Model Number42BYGHL842
Minimum Order Quantity50
PriceUSD
Packaging DetailsCarton with Inner Foam Box, Pallet
Delivery Time25 DAYS
Payment TermsL/C, D/P, T/T, Western Union, MoneyGram
Supply Ability10000 PCS/MONTH
GET AN ESTIMATE NOW

Leave a Message

Product Details



Product NameLinear Stepper MotorStep Accuracy± 5%
IP LevelIP40Insulation Resistance100MΩ Min.500VC DC
Ambient Temperature-20℃~+50℃Temperature Rise80 ℃ Max
Voltage5.61VDielectric Strength500VAC 1 Minute
Max Radial Force28N (20mm From the Front Flange)Max Axial Force10N
High Light
mini linear stepper motor, Nema Linear Stepper Motor, Linear Drive Stepper Motor



Product Description



42BYGHL842 NEMA 17 1.8° 4 leads 0.45 Nm linear stepper motor mini actuator

Screw Specification 42BYGHL842 Tr 8*8(P2) 4 heads

The linear Nema 17 stepper motor is IP40, and the working temperature is -20℃~+50℃.  It has a holding torque of 4.5 kg. cm.

The products can be customized by special request.



Electrical Specification



Model Number
 42BYGHL842
Step Accuracy
± 5%
Step Angle
1.8°
Lead Wire
4
Voltage (V)
5.61
Current (A/Phase)
1.7
Holding Torque (kg.cm)
4.5
Resistance (Ω/phase)3.3
Inductance (mH/phase)3.7
Motor length (MM)48
Motor Weight(Kg)0.36
Insulation ClassB



*Products can be customized by special request.

Mechanical Dimension
Miniature Linear Stepper Motor Nema 17 42bygh 0

Based on all these advantages, our company specializes in producing hybrid stepping motors, DC brushless motors, servo motors, gearbox motors, and so on. The products are applied in robots, packing machinery, textile machinery, medical instruments, printing machinery, intelligent logistics equipment…  TB-Motor also sends its products to the USA, Europe, Southeast Asia and all-around China.

Miniature Linear Stepper Motor Nema 17 42bygh 1
