Nema 23 Stepper Motor 12 kg cm 169oz In 1.2 Nm 1.5A Single Shaft 1.8 Degree 57BYGH416-12
| Place of Origin | China |
|---|---|
| Brand Name | TB-Motor |
| Certification | CE ROHS ISO |
| Model Number | 57BYGH416-12 |
| Minimum Order Quantity | 50 |
| Price | USD |
| Packaging Details | Carton with Inner Foam Box, Pallet |
| Delivery Time | 25 DAYS |
| Payment Terms | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability | 10000 PCS/MONTH |
Leave a Message
Product Details
| Product Name | Hybrid Stepping Motor | Step Accuracy | ± 5% |
|---|---|---|---|
| Temperature Rise | 80 ℃ Max | Insulation Resistance | 100MΩ Min.500VC DC |
| Ambient Temperature | -20℃~+50℃ | Dielectric Strength | 500VAC 1 Minute |
| Max Radial Force | 75N (20mm From Front Flange) | Max Axial Force | 15N |
| Motor Length | 56mm | Motr Weight | 0.7kg |
| High Light | nema 23 57mm,nema 23 single shaft stepper motor,Nema 23 Stepper Motor 12 kg cm | ||
Product Description
57BYGH416-12 1.8 Degree single shaft 1.5A 1.2 Nm Nema 23 Stepper Motor
57BYGH001A 1.8 degree, 4 leads, 6V, 0.5A, 0.35NM
57BYGH201-22A 1.8 degree, 4 leads, 6.6V, 0.6A, 0.6NM
57BYGH801-01 1.8 degree, 6 leads, 3.3V, 3A, 1.6NM
Please scroll down to see more specification of 57BYGH series.
| Product Name: | Hybrid Stepping Motor | Step Accuracy: | ± 5% |
|---|---|---|---|
| Temperature Rise: | 80 ℃ Max | Insulation Resistance: | 100MΩ Min.500VC DC |
| Ambient Temperature: | -20℃~+50℃ | Dielectric Strength: | 500VAC 1 Minute |
| Max Radial Force: | 75N (20mm From Front Flange) | Max Axial Force: | 15N |
| Motor Length: | 56mm | Motr Weight: | 0.7kg |
Electrical Specification
Model Number | 57BYGH416-12 |
Step Accuracy | ± 5% |
Step Angle | 1.8° |
Lead Wire | 4 |
Voltage (V) | 4.95 |
Current (A/Phase) | 1.5 |
Holding Torque (N.m) | 1.2 |
| Resistance (Ω/phase) | 3.3 |
| Inductance (mH/phase) | 8.5 |
| Motor length (MM) | 56 |
| Motor Weight(K/g) | 0.7 |
| Insulation Class | B |
*Products can be customized by special request.
Wiring Diagram
| MODEL | STEP ANGLE (°/STEP) | LEAD WIRE (NO.) | VOLTAGE (V) | CURRENT (A/PHASE) | RESISTANCE (Ω/PHASE) | INDUCTANCE (MH/PHASE) | HOLDING TORQUE (KG.CM) | MOTOR HEIGHT L(MM) | MOTOR WEIGHT (KG) |
|---|---|---|---|---|---|---|---|---|---|
| 57BYGH001A | 1.8 | 4 | 6.0 | 0.5 | 12 | 20 | 3.5 | 41 | 0.45 |
| 57BYGH048-11 | 1.8 | 4 | 4.4 | 2.0 | 2.2 | 5.0 | 6.0 | 41 | 0.45 |
| 57BYGH201-22A | 1.8 | 4 | 6.6 | 0.6 | 11 | 25 | 7.0 | 51 | 0.65 |
| 57BYGH218-45 | 1.8 | 4 | 2.6 | 2.0 | 1.3 | 4 | 8.0 | 51 | 0.65 |
| 57BYGH420-77 | 1.8 | 6 | 3.8 | 2.0 | 1.9 | 3.5 | 9.0 | 56 | 0.70 |
| 57BYGH432-63A | 1.8 | 6 | 2.4 | 3.0 | 0.8 | 1.2 | 9.0 | 56 | 0.70 |
| 57BYGH633-131 | 1.8 | 6 | 3.0 | 3.0 | 1.0 | 1.8 | 13.5 | 78 | 1.00 |
| 57BYGH639-10E | 1.8 | 4 | 2.1 | 4.2 | 0.5 | 1.6 | 18 | 78 | 1.13 |
| 57BYGH801-01 | 1.8 | 6 | 3.3 | 3.0 | 1.1 | 2.5 | 16 | 84 | 1.13 |
| 57BYGH815 | 1.8 | 4 | 7.36 | 1.6 | 4.6 | 16 | 20 | 84 | 1.13 |
*Products can be customized by special request.
*Can match with gearbox 42, 52, 56
Based on all these advantages, our company specializes in producing hybrid stepping motors, DC brushless motors, servo motors, gearbox motors, and so on. The products are applied in robots, packing machinery, textile machinery, medical instruments, printing machinery, intelligent logistics equipment… TB-Motor also sends its products to USA, Europe, Southeast Asia, and all-around China.
Applications of Stepper Motor:
-3D printing equipment.
-Textile machines.
-Printing presses.
-Gaming machines.
-Medical imaging machinery.
-Small robotics.
-CNC milling machines.
-Welding equipment.
